Rock Bolts and Soil Nails: Steel Systems for Ground Support
Wholesale, mill-certified reinforcing steel — export-direct at mill prices.
Reinforcing the ground itself
Rock bolts and soil nails stabilise slopes, excavations and tunnels by putting steel into the ground so it acts as a reinforced mass. Soil nails are passive (mobilise as the ground moves); rock bolts can be passive or tensioned. Both rely on high-strength bar bonded in a grouted hole with a face plate.
The bar systems used
Continuous thread bar (grade 500/550, Ø20–40 mm) is the workhorse — couplable, cut anywhere, anchored by a nut and plate. Self-drilling hollow bar suits collapsing soils where you drill, grout and reinforce in one pass. Corrosion protection scales with design life — galvanizing, sheathing or double corrosion protection for permanent works.
Where they’re used
Cut slopes and retaining excavations (soil nail walls with shotcrete facing), tunnel and mine roof support (rock bolts), and slope stabilisation. We supply the full kit — thread bar or hollow bar, couplers, nuts, plates and centralisers — mill-certified and matched as a system.
FAQ
What is the difference between a rock bolt and a soil nail?
Rock bolts (often tensioned) support rock/tunnel faces; soil nails are passive bars reinforcing soil slopes and excavations.
What steel is used for soil nails?
High-strength continuous thread bar, or self-drilling hollow bar in collapsing ground, grouted with a face plate.
Do ground anchors need corrosion protection?
Permanent works do — galvanizing, sheathing or double corrosion protection depending on design life and aggressivity.
Need thread bar systems at export prices?
Send sizes, tonnage and destination — written wholesale quote against today’s mill schedule within 24 hours. See Thread Bar Systems, all products and export & delivery.
Request a quote →
